General Info

Model

Soltera 2.5 Ebike

Weight

46 lbs

Total Weight Limit

300 lbs

Rider Height

S 5'1"-5'5", M 5'5"-5'9", L 5'10"-6'2"

Box Size

59 x 11 x 33

Ebike Class

Class 2 Ebike

Safety Certifications

UL and TUV Safety Certified
UL 2849 / UL 2271

Battery Safety Certifications

Certified to UL 2271

Range

Up to 46 Miles

Ideal Use

Urban Riding

Pedal Assist

4 Levels

Water Resistance

IPX5

Frameset

Frame

6061 Double-Butted Aluminum Alloy with Internal Battery

Fork

AE-E09 Soltera AL fork

Rear Spacing

142mm

Fork Spacing

100mm

Frame Style

Step-Over

Wheelset

Front Wheel

700c, 36-spoke, double-wall aluminum rim, black finish, with a nutted hub drive motor, 13g stainless steel spokes (267mm NDS/269mm DS), Presta valve.

Rear Wheel

700c, 36-spoke, double-wall aluminum rim, black finish, with a nutted hub drive motor, 13g stainless steel spokes (243mm NDS/242mm DS), Presta valve.

Tires

Kenda K1085 700x38C

Ebike System

Speed

Class 2

Motor

36V, 350W sustained, 540W peak brushless hub motor

Motor Torque

45Nm

Display

Aventon BC280

Battery

Removable Internal Lithium-ion 36V,9.6Ah(345.6Wh) with LG Cells

Battery Weight

4.14 lbs

Controller

36v 15A

Throttle

Aventon LH Handlebar Mounted

Sensors

Double Sided Bottom Bracket Torque Sensor

Charger

36V, 2 amp fast charger

Charging time from 0% to 100%

4-5 Hours

Lights

Front and rear lights integrated

Brakes

Front Brake Rotor

180mm 6 bolt

Rear Brake Rotor

180mm 6 bolt

Front Brake

Tektro HD-T280 Hydraulic disc brake w/o e-cutoff

Rear Brake

Tektro HD-T280 Hydraulic disc brake w/o e-cutoff

Drivetrain

Rear Derailleur

Shimano Tourney RD-TY300D 7 speed

Shift Lever

Shimano 7 speed twist RevoShift

Chain

7/8 speed 110 link

Freewheel

Shimano MF-TZ500-7 Freewheel, Speed : 7, 14-28T

Chainring

48T

Chainring BCD

130

Crankset

3pc, 170mm crank arm

Bottom Bracket

Square Taper, Sealed, Dual-Sided Torque Sensor

Pedals

9/16" Alloy Platform

Cockpit

Seatpost

Aventon 27.2

Seat Clamp

Aventon 31.8

Handlebars

Aluminum 31.8mm, 620mm

Grips

Lock on grips with twist shift

Headset

Aventon headset with integrated cable routing

Saddle

Aventon Saddle
