Pace 4 Step-Through Ebike
The Aventon Pace 4 is the next-generation cruiser you've been waiting for.
-
Model
Pace 4 Step-Through Ebike
Weight
58.2 lbs
Total Weight Limit
300 lbs
Rider Height
R: 4'11" -5'7" | L: 5'7" - 6'1"
Range
Up to 70 Miles
Ebike Class
Class 2 (Can be converted to Class 3 if local laws and regulations allow)
Battery Safety Certifications
Bike Safety Certifications
Ideal Use
Cruising
Water Resistance
Bike - IPX5 // Components - IPX6
Frameset
Frame
6061 Aluminum, Gravity Cast Front Triangle
Fork
Rigid Aluminum Fork
Rear Spacing
142mm
Fork Spacing
100mm
Wheelset
Front Wheel
27.5", 36 hole, Nutted axle, Schrader Valve
Rear Wheel
27.5", 36 hole, Nutted hub drive motor, Schrader Valve
Tires
27.5" x 2.1"
Ebike System
Motor
36v, 500W
Motor Torque
60Nm
Motor Power
500W
Display
Aventon BC147
Battery
Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells
Battery Weight
8.7lbs
Controller
36V, 24A
Throttle
Aventon LH Handlebar Mounted
Sensors
Double Sided Bottom Bracket Torque Sensor
Charger
36V Output: 42V/ 4A
Charging time from 0% to 100%
5 hours
Lights
Front and rear lights integrated
Brakes
Front Brake
Tektro Hydraulic w/ E-Cutoff
Rear Brake
Tektro Hydraulic w/ E-Cutoff
Front Brake Rotor
180mm 6 bolt
Rear Brake Rotor
180mm 6 bolt
Drivetrain
Rear Derailleur
Shimano Altus 8-Speed
Shifter
Shimano 8-Speed Trigger
Chain
7/8 speed 122L
Cassette
12-32T / 8 Speed Shimano CS HG200-8
Chainring
48T
Chainring BCD
N/A
Crankset
3pc, 170mm crank arm
Bottom Bracket
Square Taper, Sealed, double sided Torque Sensor 83mmx158.5mm
Pedals
9/16" Composite Platform
