General Info

Model

Aventure 3 Ebike

Weight

76 lbs

Total Weight Limit

400 lbs

Rider Height

R: 5'3" -5'10" | L: 5'10" - 6'4"

Ebike Class

Class 2 Ebike

Range

Up to 65 miles

Battery Safety Certifications

Certified to UL 2271

Ideal Use

All-Terrain

Bike Safety Certifications

UL Safety Certified
UL 2849

Water Resistance

Bike - IPX5 // Components - IPX6

Pedal Assist

3 Levels + Boost Mode (with Ride Tune Customization)

Frameset

Frame

6061 Aluminum, Gravity Cast Front Triangle

Fork

Aventon/Zoom Suspension Fork, 80mm travel, with lockout

Rear Spacing

190mm

Fork Spacing

135mm

Frame Style

Step-Over

Wheelset

Front Wheel

26", 36 hole, 13g, Double Wall Aluminum Fat Tire Rim, Nutted Axle, Schrader Valve

Rear Wheel

26", 36 hole, 12g, Double Wall Aluminum Fat Tire Rim, Nutted Hub Drive, Schrader Valve

Tires

Inova 26x4.0 puncture resistant

Ebike System

Speed

Class 2

Motor

36V, 750W Hub Drive

Motor Torque

80Nm

Motor Power

750W (1188 Peak)

Display

Aventon BC280

Battery

Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells

Battery Weight

8.7lbs

Controller

36V/33A

Throttle

Aventon LH Handlebar Mounted

Sensors

Double Sided Bottom Bracket Torque Sensor

Charger

36V Output: 42V/ 4A

Charging time from 0% to 100%

5 hours

Lights

Front and rear lights integrated

Brakes

Front Brake

Tektro HD-E3520 hydraulic disc brakes w/ EJ1 quick disconnect wire

Rear Brake

Tektro HD-E3520 hydraulic disc brakes w/ EJ1 quick disconnect wire

Front Brake Rotor

Tektro 180mm 6 bolt

Rear Brake Rotor

Tektro 180mm 6 bolt

Drivetrain

Rear Derailleur

Shimano Altus 8-Speed

Shifter

Shimano 8-Speed Trigger

Chain

7/8 Speed 118L

Cassette

12-32T / 8 Speed Shimano CS HG200-8

Chainring

48T

Chainring BCD

N/A

Crankset

3pc, 170mm crank arm

Bottom Bracket

100x177 Square Taper, Double Sided Torque sensor bottom bracket

Pedals

9/16" Alloy Platform
